Technical Parameters

Product Features

            A.High detection efficiency with two sets of built-in robotic arms for online detection and analysis, enabling high-speed online                                                     inspection.

             B.The software automatically measures the alignment of the positive and negative electrodes of the battery, and statistics such as                                             maximum, minimum, average, positive deviation, and negative deviation are calculated.

             C.The software automatically judges good and bad products and sorts out the defective ones.

             D.The automatic software judgment reduces human error, improves product consistency, and ensures quality.

             E.It has a scanning function to record battery codes, track battery test results individually, and upload them to a terminal server.

             F.The software is independently developed and can be customized according to specific customer needs.

             G.The equipment's input and output ports can be connected to the production line.

             H.Fast and simple model changeover and debugging, allowing quick adjustment for different product models.

              I.The equipment has a safety interlock function. All doors and windows are equipped with high-sensitivity photoelectric switches.

                Once the doors or windows are opened, the X-ray tube will automatically turn off to prevent human error.

Application Fields

              Used to detect the alignment of wound batteries, measure the length of the negative electrode exceeding the positive electrode at each

               layer of the diagonal or four corners, and calculate various values.

Imaging Effects
